[ใหม่] บาร์โค้ด LS2208 เครื่องสแกนบาร์โค้ด อ่านบาร์โค้ดเร็ว 100 ครั้งต่อวินาที เชื่อมต่อ USB ideal for retail, hospital, education or government settings. Corded 1D Single line 5 ft. (1.5 m) drops to concrete
436 สัปดาห์ ที่แล้ว
- กรุงเทพมหานคร - เขตวังทองหลาง - คนดู 44
3,000 ฿
รายละเอียด
SYMBOL LS2208 GENERAL PURPOSE BARCODE SCANNER
The affordable Symbol LS2208 handheld barcode scanner provides fast, reliable scanning in an ergonomic, lightweight form. The wide working range —from near-contact to 17 inches — makes this device ideal for retail, hospital, education or government settings. Multiple on-board interfaces ensure integration with a variety of host systems.
Durable, single-board construction
Meets stringent 5-ft drop tests.
Scratch-resistant tempered glass exit window
Is designed for continuous use.
Accurate first-time capture of 1-D barcodes
Increased productivity, resulting in shorter check-out lines and better customer service.
Wide working range
Delivers optimal performance from contact to 17 in (43 cm).
Multiple on-board interfaces
Simplify installation and integration and ensures future compatibility.
Plug-and-play, with universal cable
Means rapid deployment, with a single cable connecting to any computing environment.
Intuitive design
Minimizes setup and training time.
Ergonomic, lightweight design
Reduces user fatigue with sleek, balanced form for maximum comfort and productivity.
Hands-free Intellistand
Enables presentation scanning and easy switching between hands-free and handheld modes.
Advanced Data Formatting (ADF)
Enables users to modify data prior to sending to host computer, reducing costly modifications to the host software.
SPECIFICATION SHEET
LS2208 Specification Sheet
Notices and Disclaimers
See footnote1
Performance Characteristics
Scan pattern
Single line
Minimum resolution
20% minimum reflective difference
Interfaces supported
IBM, Keyboard wedge, RS-232, Synapse, USB, Wand
Pitch2
2 +/-65 degrees
Roll (Tilt)3
1 +/-30 degrees
Skew (yaw)4
3 +/-60 degrees
Depth of field
From contact to 17 in./43 cm on 100% U.P.C./EAN symbols
Decode capability
1-D, See data sheet for full list of supported symbologies
Technology
Laser
Physical Characteristics
Dimensions
6 in. H x 2.5 in. W x 3.34 in. D 15.2 cm H x 6.3 cm W x 8.4 cm
Voltage and current5
5 volts +/- 10% at 130 mA typical, 175 mA max
Color
Twilight black, Cash register white
Corded
Yes
Weight
5.15 oz./146 gm
Power source
Host power or external power supply (depends on host type)
Handheld
Yes
Regulatory Specifications
Electrical safety
UL 60950-1, C22.2 No. 60950-1, EN 60950-1, IEC 60950-1
Laser/LED safety
EN 60825-1, IEC 60825-1, 21CFR1040.10
EMI/RFI
FCC Part 15 Class B, ICES 003 Class B
Environmental
RoHS Directive 2002/95/EEC
User Environment
Operating temperature
Operating temperature 32° to 122° F/0° to 50° C
Drop specifications
Unit functions normally after repeated 5 ft./1.5 m drops to concrete
Storage temperature
-40° to 158° F/-40° to 70° C
Ambient lighting tolerance
Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions. Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED : 450 Ft Candles (4, 844 Lux) Sunlight: 8000 Ft Candles (86, 111 Lux)
1 Does not include cable.
2 Pitch: Controlled by dropping or raising the wrist
3 Roll (Tilt): Controlled by rotating the wrist clockwise or counterclockwise
4 Skew (Yaw): Controlled by rotating the wrist from left to right or vice versa
5 Specifications are subject to change without notice.
